Graph algorithms, full paths, and the work a benchmark must count

The graph-algorithm benchmark on adversari.al compares implementations on identical generated graphs. Its most revealing experiment is a chain of 65,536 nodes, where every implementation computes shortest paths and constructs and consumes the full node sequence and cumulative-cost sequence for every reachable destination. Neo4j is allowed to finish.

The important change came before any timing. We had to agree on what the result contained. Everything after that — three rounds of optimization, two regressions, and one correctness bug — followed from having an output contract explicit enough to argue about.

A distance is not a path

A shortest-distance query returns one number for each destination. A full-path query also returns the intermediate nodes and the cost accumulated along that route. Those are different output contracts, even when both operations are called Dijkstra.

A chain makes the difference concrete. The path to the source contains one node. The path to the next contains two, then three. Across all destinations, each array contains n(n + 1) / 2 entries. At 65,536 nodes that is 2,147,516,416 entries in the node-ID array and the same number in the cumulative-cost array, for each engine.

Nothing is summed in closed form, no graph family is special-cased, and paths are reconstructed one at a time into reused buffers rather than retained together. The mode removes both the native process deadline and the Neo4j transaction deadline.

Columns are execution classes, not engines

The first published run had five columns. Icebug is the Apache Arrow update of the C++ NetworKit codebase. Icecat is the Rust rewrite. Grustcat is the Grust-compatible implementation with an Arrow projection. Grustcat Cypher adds a parser and semantic analyzer over a focused typed Arrow backend. The fifth is Neo4j Community with official GDS and its unmodified single-source Dijkstra procedure.

That run, one sample per cell with no warmup, in Linux ARM64 Docker on an Apple M1 Max, in seconds:

Every number later in this post comes from a different machine — an 8-vCPU Xeon in EC2 — and none of them belong in that table. Graph loading and projection sit outside the reported timers. Native timings include the algorithms, reconstruction and aggregation; Neo4j's is server query time including Cypher aggregation.

The gap in that lineup is the one that mattered. Grustcat Cypher is a typed Arrow adapter — a Cypher-shaped front end over a fast path, and the repository always said so. It is not the general query executor. So the benchmark had never measured what an ordinary Cypher query costs.

Six more columns, and a ninety-fold question

Pointing the same protocol at current upstream sources added six: native execution on current kernels, the general Cypher executor, an Arrow-native path, DataFusion scan-plan preparation, and Grust algorithms over a verified snapshot from a durable Turso database. Eleven columns, all with deliberately unequal and disclosed boundaries.

Ordinary Cypher came in at roughly ninety times direct execution — nearly ninety minutes for one full-path query at 65,536 nodes.

The obvious suspect was the query shape. The benchmark's Grust column expands one row per path entry with UNWIND; Neo4j's GDS query folds each path in place with reduce. At 65,536 nodes that is 2.1 billion interpreter rows against 65,536.

It was not the query. Removing the row expansion entirely — asking only for count(*) and sum(size(nodeIds)) — saved about 4%: 20,804 ms against 21,721. And the fold shape could not be written at all, because Grust's Cypher had no reduce to write it with.

perf put about 83% of the time in _vdsoclock_gettime and its syscall path. The bounded read policy requires a finite deadline, this participant disclosed a 24-hour ceiling, and the execution context checked that deadline on every charge against the work budget — once per path entry, roughly 8.4 million times at 4,096 nodes. Direct execution sets no deadline, skips the clock, and finished the same work in 197 ms.

Two things turned that from an engine result into a policy result. The host's clocksource is xen, not tsc, so every read goes through a paravirtual clock instead of a register. And GDS samples its own termination check: the shipped gds.jar carries RUNCHECKNODECOUNT = 10000 and INTERVALMS = 10000, so its algorithms consult a cached flag every ten thousand nodes and that flag re-reads the clock every ten seconds. Grust checked every unit. What looked like an executor deficit was one engine sampling and the other not.

Grust now samples too, every 1024 charges — an order of magnitude tighter than the engine it is measured against. Cancellation is never sampled, budget limits still fail exactly at their limit, and an explicit checkpoint still reads the clock every time.

The meter cost more than the work it guarded

Profiling the native path found the same shape of problem underneath. 72.8% of kernel self time in full-path Dijkstra was charge_work — the cooperative budget meter — against 14.8% for visiting paths. Kernels charge per visited entry, and the meter took a mutex on every call: about 134 million lock acquisitions in a single-threaded kernel.

Making the counter and cancellation flag atomics, with admission recomputed through a compare-exchange so budgets are still enforced exactly, improved full-path Dijkstra by up to 29.4% on direct execution — except on hub graphs, where it was flat — and PageRank by 22.5 to 29.1% across families.

Then the same problem once more, one layer down. A streaming CALL was deep-copying every yielded value into each row, so a path list was cloned once per path, and work was still charged per entry even after charging became cheap. Borrowing the yielded lists and admitting work per path — or per 1024 steps — took direct execution on the 16,384-node chain from 3,190 ms to 1,298 ms and ordinary Cypher from 36,913 ms to 20,255 ms. At 4,096 nodes with five measured samples, direct improved 58.7% and ordinary Cypher 45.2%.

The meter was never one problem. It was the same problem in three places.

On the 65,536-node chain, the full run fell from 3 hours 32 minutes to 35 minutes, with ordinary Cypher going from 5,808,625 ms to 594,419 ms. Throughout, the four frozen historical binaries are byte-identical across every run and moved by at most 1.4%. That control is what makes the rest attributable to the code rather than to the machine.

The benchmark found a correctness bug, and it was not in an algorithm

A durable-loading experiment failed all 36 of its samples. Neither group commit nor the journal mode was responsible: results were associated with nodes by position in the snapshot rather than by node identifier. Bulk loading inserts in input order, so position and identifier coincided and the defect was invisible. Four concurrent writers scrambled insertion order, and every distance landed on the wrong node.

The returned values were an exact permutation of the reference — identical multisets, wrong positions. Snapshot verification could not catch it, by construction: it compares sorted records, because database scan order is legitimately arbitrary, which makes it blind to a permutation. No published number was affected, because every published run used bulk loading. What caught it was the benchmark's own per-sample comparison against a C++ reference.

What did not work

reduce now exists in Grust's Cypher. It returns aggregates identical to the UNWIND form, and it is slower: 4.6 to 4.9 times on the pin where it landed, and about 6.1 times on current code, where the row-expansion path improved faster than the fold did. The benchmark keeps the row-expansion shape.

The reason it stays slower is the same problem one axis over. Work accounting is now lock-free, but each folded element still evaluates through the general scoped evaluator, and every variable reference clones a value and charges its bytes through a memory account that takes the state mutex. Two references per element means two lock round-trips plus a string allocation, and the per-entry string is inherent to path node identifiers being a string type. Closing the gap needs either byte accounting without the mutex — exactly what work accounting already got — or a compiled fold. Neither is in this release, which is why the shape stays as it is.

That comparison has shifted in an interesting way. When the clock reads dominated, removing the row expansion was worth about 4% and the query shape was irrelevant. On current code the same measurement is 1,533 ms against 718 ms without the expansion — the shape is now worth about half the query. The fold is still the slower way to write it, but the prize for making it fast is no longer rounding error.

A first attempt at deadline sampling regressed every path that sets no deadline by 13 to 46%, because the sampling counter ticked whether or not a deadline existed. It reached main before the paired measurement that would have caught it. The fix returns before both the counter and the clock when there is no deadline, and a re-measurement put every affected cell back within dispersion.

An audit of this post's own numbers against the retained samples found three ranges stated more favourably than they measured, and corrected them.

Both kinds of failure are here because a benchmark that publishes only the changes that worked is not measuring, it is advertising.

Evidence beyond one chain

The historical variants pass 30 small cases: six graph families across BFS, Dijkstra, weak and strong components, and PageRank. The runtime image passes 45 kernel and Arrow interchange checks; the current-source images add 216. Every matrix run for this work — 60 cases at 128 and 1,024 nodes, 30 at 4,096, on each source pin — passed, as did 2,016 paired samples across four sweeps.

Those checks keep algorithm-specific distinctions visible. BFS compares reachability and level order because native and GDS result shapes differ. Component partitions are canonicalized. PageRank uses the same weighted model but different convergence rules, checked within recorded tolerances. There is no combined score that hides the differences.

The large chain has unique shortest paths, so every distance, the path-entry count, the node-ID sum and the cumulative-cost sum are independently calculated and compared. Matching aggregates on a tied graph would not, by itself, prove every interior node correct.

What these numbers are not

Not a ranking of engines: the columns are execution classes with unequal, disclosed boundaries. Not portable — the clock findings are shaped by one host's xen clocksource, and a TSC host would show a smaller penalty for the same code. The 16,384 and 65,536 results are single samples establishing completion, not stable rankings. Results from four source pins are kept in four separate sets and never pooled, and the M1 Max table above is not comparable with any of them.

Reproducing it

git clone https://github.com/querygraph/adversarial-graph-algorithms
cd adversarial-graph-algorithms

# the published September measurement, from the checksum-verified snapshot
./docker/run.sh --frozen --output /tmp/frozen -- --full-path --algorithms dijkstra \
  --families path --sizes 16384 65536 --warmups 0 --repeats 1 --label reproduced

# current sources: Grust and Turso at their pinned commits, with Arrow,
# DataFusion and the mimalloc allocator
./docker/run.sh --output /tmp/current -- --full-path --sizes 128 1024 \
  --warmups 1 --repeats 5 --label current

The repository carries a checksum-verified snapshot of the measured source, so the frozen run needs no sibling checkouts; official Neo4j and GDS archives are downloaded and checksum-verified separately. The samples behind every table are committed under publication/evidence/, with checksums, so the distributional claims — the cells, the medians, the dispersions — are recomputable without rerunning anything.

The Graph tab indexes this alongside the graph-query benchmark and the strain ledger. Their datasets, protocols and execution classes are not pooled into one leaderboard. The Adversarial Cognition book carries the longer discussion of testable boundaries. Here the boundary is the output itself: what must exist, what must be consumed, and what the clock includes.
